KH0028C-NC數控彎管槽機
Digital-control Tube & Frame Curve-shaping Machine
數控滾彎，輸入弧長及R，修改參數方便快捷
Digital control bending, modify the parameters conveniently just set the radian & R
不同型材選用不同滾輪
Different profile deploy different roll
確定數值，儲存數值，批量生產
Determine and save numericals, effective to production.
數控進給壓輪，壓力均衡，可選微量進給
Presssure roll goes by digital control, pressure balanced and optional micro-feed
彎管范圍：1″×1″扁管, 1″×2″扁管, 1″×3″扁管,1″×4″扁管，也可根據客戶型材
Range of tube curving: flat tube 1″×1″ 1″×2″ 1″×3″ 1″×4″, also can be based on
customer’s profile
管壁厚Tube wall thickness：2mm-4mm
輸入功率Input power：驅動電機Drive motor 1.5KW 進給電機feeding motor 0.75KW
輸入電源Input supply：380V 50HZ
外型尺寸External dimensions ：機臺 machine 680mm×1000mm×1500mm
數控箱digital box 500mm×325mm×1010mm
重量Weight：550KG
